Linking Iphone/Siri to control Vera?

Apps & Remote Access
#41

Can anybody confirm if the CT-100 thermostat will work with Siri Proxy.
Uncommented the 3 lines in the config.yml file for the thermostat plugin. since the CT-100 is not ip enabled I set the ip address to the vera box. Ran siriproxy bundle and update. If ask for the thermostae status it just tells me it is off. Running command bundle show I see "siriproxy-thermostat 0.0.1 badb55d. Any ideas on the badb55d

#42

[quote=“Gjones, post:35, topic:169387”]Hi

I’ve listed my commands for turning a device off, setting the DIM level and reporting the thermostat temperature. To return the status i used HTTParty. I didn’t get time to work out how to load the HTTParty gem seperately so just enabled the default thermostat plugin in the /.siriproxy/config.yml file which installed it for me

#Turn Device off
listen_for /Living room light off/i do
open(‘http://10.0.30.35:3480/data_request?id=lu_action&DeviceNum=35&serviceId=urn:upnp-org:serviceId:SwitchPower1&action=SetTarget&newTargetValue=0’)

#Set Dim Level
listen_for /Living room light ([0-9,]*[0-9])%/i do |dimlevel|
say “Set Living room light to: #{dimlevel} percent.”
open(“http://10.0.30.35:3480/data_request?id=lu_action&DeviceNum=35&action=SetLoadLevelTarget&serviceId=urn:upnp-org:serviceId:Dimming1&newLoadlevelTarget=#{dimlevel}”)

listen_for /Hall temperature/i do
halltemp = HTTParty.get(“http://10.0.30.35:49451/data_request?id=lu_variableget&serviceId=urn:upnp-org:serviceId:TemperatureSensor1&Variable=CurrentTemperature&DeviceNum=14”)

    say "Hall temperature #{halltemp} degrees."

[/quote]

So I have been working on this project for a little while now and I finally have SiriProxy running on the Raspberry Pi. I am having problems with getting it to control my devices. I hope someone can assist me:

As an example I am trying to get SiriProxy to lock/unlock my Kwikset Deadbolt. Here is the code I have entered into the SiriProxy-example.rb file:

#Unlock Foyer Deadbolt
  listen_for /Unlock Deadbolt/i do
    open("http://192.168.0.5:3480/data_request?id=lu_action&output_format=xml&DeviceNum=4&serviceId=urn:micasaverde-com:serviceId:DoorLock1&action=SetTarget&newTargetValue=0")

  request_completed #always complete your request! Otherwise the phone will "spin" at the user!
  end

I get the following response from SiriProxy when I issue the Unlock Deadbolt command:

Plugin Crashed: No such file or directory - http://192.168.0.5:3480/data_request?id=lu_action&output_format=xml&DeviceNum=4&serviceId=urn:micasaverde-com:serviceId:DoorLock1&action=SetTarget&newTargetValue=0

I can enter that http string into a browser and the Deadbolt does unlock. Any ideas?

**EDIT. Disregard I figured it out.

I was missing the require ‘open-uri’ at the beginning of the example file.

#43

I want to use the example dim control code and use it for setting a thermostat. What variable is available other than “%” in the line

#Set Dim Level
listen_for /Living room light ([0-9,]*[0-9])%/i do |dimlevel|

Tried putting in a word instead of % and it did not like it

#44

Hi
I hope you find this video helpful
